PS-HDE100
HDMI Extender 100M HDBaseT
The PS-HDE100 HDMI Extender utilizes advanced HDBaseT technology to transmit HDMI video, bi-directional IR and RS-232 control signals over a single CAT5e/CAT6/CAT7 cable. Designed for professional AV installations, it supports Full HD, UHD, 3D and 4K60Hz (4:2:0) video transmission.
Key Features
- HDBaseT extension over single CAT5e/6/7
- Supports Full HD, UHD, 3D and 4K60Hz (4:2:0)
- HDMI 2.0 and HDCP 2.2 compliant
- Bi-directional IR and RS-232 control
- Power over Cable (POC)
- EDID pass-through
- CEC support
- DTS Master HD and Dolby TrueHD support
Technical Specifications
| Model | PS-HDE100 |
|---|---|
| Technology | HDBaseT |
| HDMI Standard | HDMI 2.0 |
| HDCP | HDCP 2.2 |
| Resolution | Up to 4K60Hz (4:2:0) |
| Bandwidth | 10.2Gbps |
| Distance | Up to 100m |
| Cable Type | CAT5e / CAT6 / CAT7 |
| Power Supply | DC 12V / 1.5A |
| Power Consumption | ≤10W |
Refer to the datasheet for complete operating conditions and model selection.
